AFFINITY m duo

Base vehicle: MAN TGE
Engine: 2.0 L, 177 HP
Gearbox: 8 gear automatic transmission
Dimensions: 684 x 219 x 290 cm

Number of seats: 2
Day
Sleeping places: 2
Night

AFFINITY m duo

Base vehicle: MAN TGE
Engine: 2.0 L, 177 HP
Gearbox: 8 gear automatic transmission
Dimensions: 684 x 219 x 290 cm

Number of seats: 2
Sleeping places: 2
Day
Night

IDEAL FOR couple

DUO M is another Affinity model designed with thought of people travelling in two. Functional solutions adapted to the needs of two users and driving comfort of the MAN TGE is a combination, which will satisfy the most demanding travellers.

CALM SLEEP

The bed in Affinity M in the unfolded form for sleeping is 132 cm wide and 190 cm long. When folded, the surface of the bed still remains large enough  to provide comfortable rest for one person. Even in the case of an unfolded bed there is an access to the toilet and shower located at the end of the vehicle.

TRAVEL MORE COMFORTABLY

An important advantage of the Affinity DUO M compared to the DUO version is a bigger capacity of the trunk. It will accommodate more accessories necessary for travel.  There is a large sized storage located under the bed.

TAKING A SHOWER IS A REAL PLEASURE

The chassis of the MAN TGE is longer than the Fiat. It allowed for use of the very practical layout of a bathroom. It is equipped with a separate shower cabin and  space in front of the it is spacious and allows for comfortable use of the sanitary section.

FLOOR PLANS

Day
4
3
2
1
2
Cassette, 19 litres
3
Gas, 2 burners
Night
1
1
132 x 190 cm

CONCEPT

Affinity DUO M is a model addressed to people who value independence. Two hundred litres clean water tank, 2 gas cylinders with the possibility to refuel at a gas stations, space for the solar panels with a high-power enable for long trips without necessity for visiting campsites and service points.  This is a model with a double floor, fully adapted for winter travels. All water tanks are located inside the vehicle.

Affinity DUO M apart from the technical facilities has very important advantages from the point of view of the user. It guarantees: a large bed, functional kitchen and a comfortable bathroom.

Innovations

External access to the gas box allows replacement of the cylinders without the need of emptying the trunk. It is a solution used very rarely in the campervans, however it’s more comfortable then popular access through the back door.

Thanks to the option of lifting two shelves, the interior of the boot can be adapted to transportation of the skis or other long objects. Luggage space provides enough space for all travel needs.

TECHNICAL SPECIFICATIONS

MAN TGE

2.0 L, 177 HP
8 gear automatic gearbox
Driver and front passenger airbag with front passenger airbag deactivation
LED headlamps with LED separately daytime running light
Read more

Standard Equipment

2 seats for driving, 2 sleeping berths
Truma Combi 4E gas-electric heating
LiFePO4 135 Ah board battery
Double floor
Cab window blinds
Electric entry step (70 cm)
Flyscreen on entry door
Roof vent with electric fan in kitchen
Skylight with electric fan in lavatory
Wall, floor and ceiling insulation
10/20 mm
Separated shower cabin
66 x 57 cm
Chemical toilet
Cassette, 19 L
Skylights
x3
Cooker
Gas, 2 burners
Refrigerator
70 L
Clean water tank (insulated)
200 L
Grey water tank (insulated)
100 L

OPTIONAL EQUIPMENT

Truma 6E heater
Truma D6E
Solar package (monocrystalline) 120W Flex MPPT, BT
Solar package (monocrystalline) 240W Flex MPPT, BT
Solar package (monocrystalline) 360W Flex MPPT, BT (option without roof air conditioning)
LiFePO4 200 Ah Winter board battery with BT
LiFePO4 300 Ah Winter board battery with BT
Gel battery
Büttner 1700 pure sine wave inverter
Inverter cabling system
Truma Aventa Comfort roof air conditioning
Wooden shower mat
Black awning
Keder Rail
Tow bar
Heated front seats
Pneumatic rear-axle suspension
Softclose
External shower
TV cabinet (holder only)
TV cabinet (holder + 18,5” TV)
TV cabinet (holder + 18,5” Smart TV)
External TV socket
LCD control panel
Caratec LTE Antenna plus router
Oyster Connect
LCD control pane
2 additional speakers
Mattress with additional layer
Bed sheet with Affinity Logo
Seat cover with Affinity logo

DIMENSIONS AND WEIGHT

Length
684 cm
Width
219 cm
Height
290 cm
Weight in running order
3120 kg
Interior height
195 cm
French bed dimensions
190 x 132 cm
Mass of the vehicle in running order is defined as the mass of the vehicle including equipment, fuel tank 90% full, 75 kg driver weight, full 11L aluminium gas bottle, 20L of water in the system. Margin of error +/- 5%.
